SNAT634PAC 61049452D

The SNAT634PAC 61049452D includes a ControlLogix module that provides OPC UA server functionality in the chassis. As a result, ControlLogix systems can exchange data with OPC UA clients.The OLDI module supports the on-the-fly creation of structures for unknown data types, including complex data created from user-defined tags in ControlLogix programs. Features a high-resolution widescreen 7-inch WVGA color touchscreen with 1000 nits of brightness. The display has high outdoor visibility, allowing the XL7 to be used in a variety of environmental conditions. The backlit LED display allows for higher pixel resolution, enabling the end user to view more in-depth information on the screen.The XL7 includes a logic engine with built-in digital and analog I/O for in-circuit programming – an invaluable feature for machine commissioning.

Technical Data:
Operating system: Windows CE 6
32-bit controller with 400 MHz ARM9 CPU
Flash memory: 256 MB MicroSD (optional 1 GB, 2 GB or 4 GB)
Internal RAM: 64 MB RAM
Interfaces: 1 x Ethernet 10/100 MBit/s, 1 x USB device (behind front cover)
1 second UPS (for 1 MB persistent data)
