PNI800A

The PNI800A provides two independent single-ended 5-24 VDC inputs to receive pulse/directional and quadrature signals up to 100 GHz.The P1-04PWM Pulse Width Modulation Module provides four channels of sink or gain outputs from 0-20 kHz at 0-100% duty cycle for use in the Production 1000 system. The Analog Module supports 8 channels of inputs or outputs and the new 4-channel Analog Input Module provides 16-bit resolution for Horse and VDC signals.I/O modules are auto-discovered and added/removed. QR (Quick Response) codes are printed on each module for up-to-date specifications and wiring. Network communication is accomplished through the CAN port (J1939 capable) or through the serial communications port, which is a selectable field for RS-232, RS-422 or RS-485 configurations.

The PNI800A is based on chip technology on the PLC, allowing the module to be connected in a hermetically sealed, impermeable envelope under less than ideal conditions in harsh environments. The standard enclosure is submersible to three feet and is screw and sub plate mountable. The module is programmed using DeWeese Ladder software, which supports ladder diagrams and function block programming. The module has 8 to 32 VDC input power. I/O consists of six (6) 8-32 VDC inputs – two (2) of which are independently field-selectable for sinking or sourcing in addition to providing high-speed counting at 40 kHz; two (2) 10-bit analog channels field-selectable for 0-5 VDC, 0-10 VDC, or 0-20 MA; and six (6) digital/pressure-tube outputs rated at four (4) amps, each with automatic override. Each has automatic overcurrent safety and programmable status monitoring.
