J592S-450550

J592S-450550 is used to design state machines to model the behavior of real-time and embedded systems to describe event occurrences and responses for designing digital communication protocols, machine controllers, and system protection applications.LabVIEW 8.5 adds a new statechart module to help engineers use the familiar high-level statechart notation based on the Unified Modeling Language (UML) standard to design and simulate these event-based systems. Because the LabVIEW Statechart Module is based on the LabVIEW Graphics Programming Language, engineers can rapidly design, prototype, and deploy their systems on a single platform, combining familiar statechart representations with actual I/O running on deterministic real-time or FPGA-based systems.

The J592S-450550 adds enhanced vibration measurement and order analysis tools to industrial machine monitoring systems. For high-channel-count systems, the new Multivariable Editor allows users to quickly and easily configure or edit hundreds of I/O tags using a simple spreadsheet interface. In addition, the latest version of LabVIEW introduces new flexible pipeline display tools to simplify the process of building more realistic industrial user interfaces, as well as an interactive drag-and-drop method of binding I/O tags directly to industrial touchscreens and handheld PDAs running on Windows CE-based user interface displays. with LabVIEW, engineers can combine more advanced programmable automation Controller (PAC) with existing Programmable Logic Controller (PLC)-based systems to add high-speed measurement and advanced control to their industrial systems.
