IOB-80

The IOB-80 features Profibus-DP slave functionality for cyclic I/O data transfer and can handle up to 244 bytes of input and 244 bytes of output data. On the J1939 side, the gateway supports up to 35 incoming J1939 Transport Protocol (Big Message) sessions and can monitor up to 120 different PGNs in the input data point configuration and transmit up to 100 different PGNs in the output data point configuration. the J1939 Transport Protocol (Big Message) handler rejects incoming PGN/address pairs that are not configured as input data points Session Requests (BAM and RTS/CTS)

The IOB-80 was developed with 1- and 2-channel SSI expansion modules. Series SSI modules allow customers to extend the flexibility of MicroLogix 1100, 1200, and 1400 controllers by adding the ability to monitor rotary and linear applications. Programming software is available to get started. The controller and 7160 SSI module can be panel or DIN rail mounted, with the module mounted on the right side of the controller.The AMCI 7161 and 7162 SSI modules provide up to 32-bit resolution with a choice of binary or Gray code data formats. The resolution is limited only by the resolution of the SSI sensor and provides the user with scaling data, actual SSI data, or velocity data.
