IC660ELB912

The IC660ELB912 can be used for image performance verification, ADC/DAC testing, digital image transfer to large format printer/plotter applications, and digital video recording/playback. The IC660ELB912 utilizes a PCI Express x4 interface and guarantees up to 400 MB/s throughput and up to 100 MHz data rate with programmable parallel data widths (8/16/24/32 bit). (8/16/24/32-bit). Sample and update clocks can be derived from internal or external timer pacemakers and support up to 80 clock phase shifts to ensure accurate data sampling and timing updates and prevent invalid timing issues during data conversion.

The IC660ELB912 features an additional 8-channel programmable function I/O connection that can be configured for I2C/SPI master, trigger IN/OUT, external clock IN, digital input/output sample clock export, and handshaking modes to communicate, control, or synchronize with an external device or device under test (DUT). Logic levels for both high-speed and functional I/O are software programmable and support three options including 1.8V, 2.5V, and 3.3V, providing the flexibility to bootstrap interfaces to external devices and DUTs if different logic levels are required. the IC660ELB912 supports Windows 8, Windows 7, and Windows XP operating systems, and interfaces with The IC660ELB912 supports Windows 8, Windows 7, and Windows XP operating systems and is fully compatible with third-party software such as LabVIEW and Visual Studio.NET.
