DSQC604 3HAC12928-1

The DSQC604 3HAC12928-1 provides the versatility to solve a variety of interface problems between incremental encoder signals and PLCs, servo drives, or other input devices. Ideally suited for use with single-ended or differential line driver encoder signals, the module features three complementary inputs rated at 4.5-7.5 and 12-26 VDC, and a frequency response of up to 1 MHz.The FC-ISO-C High-Speed Optoisolator Module is designed with three complementary open-collector outputs rated at 5-36 VDC for use in single-ended configurations. Opto-isolation rated at 1800 V separates the input signals from the outputs. The module can convert differential line driver encoder signals to open collector single-ended signals or change the encoder signal voltage to match the receiving electronics input.

The DSQC604 3HAC12928-1 is ideally suited for use with encoder and servo drive encoder signal inputs and outputs. The module has three differential line driver outputs rated at 5VDC with 1800V opto-isolation.The FC-ISO-D module converts a single-ended encoder signal to a differential line driver signal or a differential line driver encoder signal to a single-ended signal. The module can also change the encoder signal voltage to match the receiver electronics input. Both modules are designed in slim plastic housings that include integrated 35mm DIN rail mounting adapters, LED indications, and removable screw terminal blocks for easy installation and wiring.
