200-566-000-012 200-566-101-012

200-566-000-012 The 200-566-101-012 enables the user to seamlessly integrate additional high and low power digital and analogue I/O into the system. The user imports the EtherCAT I/O configuration file into the A3200 MotionPAC PLC module, making it available to all programmers. Users then use the MotionPAC mapping tool to connect EtherCAT I/O points to tags or variables. Connections are made by dragging and dropping EtherCAT I/O names onto tags or variables defined in MotionPAC, the operator interface, or any other module of the system.MotionPAC automatically manages the memory associated with EtherCAT I/O mapping. There is no need for the programmer to allocate memory addresses. While programmers are free to view the memory assignments, they can also change or create them if needed.

200-566-000-012 200-566-101-012 The real-time and high-speed capabilities of the 200-566-101-012 enhance the software-based A3200 Machine Controller’s ability to meet the needs of large-scale, distributed applications that require decentralised and diverse I/Os. Using this technology, the A3200 can access millions of I/O points per second while controlling machine functions including high-end motion and other control loops such as temperature and pneumatic control. Modular integration is achieved by integrating the Hueyosens CIFX 50-RE card into the A3200 system and is available as an optional A3200 software driver. This new feature makes it easy to combine fieldbus I/O with drive I/O in motion and PLC programmes. Combining EtherCAT I/O with the A3200 Integrated Motion and PLC creates an ideal machine controller platform that will minimise development and commissioning time while providing a high performance solution for automation projects.
