1771-IR

The 1771-IR’s integrated protection know-how functions (e.g. against machine cloning) help prevent unauthorised access and modifications. The copy protection uses Simatic memory cards in which the individual blocks are associated with the serial number of the original memory card. This should ensure that the programme can only be run via the configured memory card and therefore cannot be copied. Access protection solves the problem of unauthorised configuration changes. For this purpose, separate rights can be assigned to different user groups via the authorisation phase. Special mechanisms are designed to identify modified engineering data – for example, to protect the data transferred to the controller from unauthorised manipulation.

The 1771-IR offers unprecedented control and monitoring functionality and value in a compact, robust remote unit.The highlight of the ACP is the intuitive application development environment. Complex logic can be programmed to interact with any point on the unit and perform all required calculations, from simple control logic to very complex algorithms.OSIRIS’ ACP provides tools to support five forms of logic language: ladder diagrams, function block diagrams, sequential function diagrams, structured text and instruction lists, and flowcharts. The programming and configuration tools have been developed for ease of use and application flexibility.
