128229-01

The 128229-01 is a compact PLC with management unit I/OS and graphic/touch/color operator interface. The visual overall HMI panel contains a graphically prepared LCD, function keypad and/or touch screen. This allows you to use graphical images and bar graphs to represent real-time variable data, create and display text commands, and display actual run-time system data. The operator uses the keypad to enter or modify system data. VISY’s management unit I/OS provides D/A inputs, including HSC/vibration encoders/frequency meters, as well as relay/transistor outputs, including piezoresistors.

128229-01 includes programming and tag generation via the commonly used touch screen or HMI. emjen’s initial process review of the software included the application of the PLC Code Generator to generate PLC programs for at least 3 different machines with a total I/O count of approximately 150. Since these machines had been previously programmed, emjen was able to provide a time and cost analysis of manually programming the machines with the generated programs. using the PLC Code Generator. Results: Average time savings of more than 80% and average cost savings of more than 50%.
